MCP2200: USB-to-UART protocol converter by Microchip Technology


MCP2200 is USB-to-UART protocol converter, which you can use as complete out-of-the-box solution that makes it easy to add USB connectivity to embedded systems. The MCP2200 enables designers to quickly add USB connectivity without completely redesigning the system. This USB-to-UART protocol converter is designed to shorten time-to-market for a variety of applications in the industrial and medical markets such as RS-232 applications. The MCP2200 includes 256 bytes of integrated user EEPROM and has eight GPIO pins. Four of the pins have alternate functions to indicate USB and communication status. The MCP2200EV-VCP Demo Board removes the burden of thoroughly understanding the USB protocol from system designers, which simplifies the addition of customizable USB functionality to existing designs.



  • USB Speed: Full Speed
  • USB Compliant: USB 2.0
  • PHY: Yes
  • MCU Interface: UART
  • Tx/Rx Buffer Size (Bytes): Tx 128 - Rx 128
  • No. of GPIO: 8
  • Operating Voltage Range (V): 3.0 to 5.5
  • Industrial: Data loggers, Instrumentation, Data-acquisition systems, Smart-card readers
  • Medical markets: Monitors for heart-rate, blood sugar, and blood pressure
  • Legacy RS-232
